Community Care Bed

CommunityBed allows equipment services to combine two beds into one. By combining the lifting height of a conventional profiling bed (800 mm) and the lowness of a conventional low bed (220 mm), CommunityBed allows equipment services to simplify their range and reduce stock.

CommunityBed is fully compliant with BS EN 60601-2-52.

HSE Approved

Key Information

• Lifts as high as a conventional profiling bed (800 mm)
• Goes as low as a conventional low bed (220 mm)
• Compliant with BS EN 60601-2-52
• Ideal for applications where there are taller carers (or similar).

Dimensions & Specifications

• Mattress platform height range: 220 to 800 mm (8.7 to 31.5 in)
• Overall dimension: 925 x 2196 mm (36.4 x 86.5 in)
• Overall dimensions with 200 mm extension: 925 x 2396 mm (36.4 x 94.4 in)
• Mattress size: 900 x 2000 mm (35.4 x 78.7 in)
• Mattress size with 200 mm extension: 900 x 2200 mm (35.4 x 86.6 in)
• Safe working load: 215 kg (34 st)
• Maximum patient weight: 180kg (28 st)
• Weight of bed (excluding transport bracket): 77.6 kg (12 st)
• Profiling functions: Backrest with Auto-regression, Kneebreak. Anti-Trendelenburg and Trendelenburg available as an option.
• Liquid ingress protection: IPX4

* External dimension may vary depending on head and footboard design
